P8mm HD Resolution Wide Viewing Angle Full Color IP65 Outdoor Advertising LED Display
Digital Billboard Description
BOF-outdoor fixed led display is an high definition media led screen, with IP65 waterproof function and 1920 refresh rate. Suitable brightness adjustable for outdoor day and night. And it is widely used in Semi-outdoor and outdoor advertising ,Competitive price,Long life time and hgih quality.
Digital Billboard Features
1. High resolution
The most apparent features of the new generation of LED display.
2.Black, White, Gray Cabinet to choose
We have three cabinet color to choose. For different country market. When the temperature is too high for a long time, the white box can be used to reduce the heat absorption.
3.Easy maintenance
After adopting the classic back maintenance,it's applied to large size LED and roof mounting,wall mounting and pillar base.
4. Steel or Aluminum material
The steel material is much cheapter than Aluminum, and the steel cabinet can be customized.
The alumunim materials has good resistance to salt spray, strong acid and corrosion resistance, good heat dissipation.
Digital Billboard Specifications
| | BOF-8 |
| Physical Pitch | 8 mm |
| Pixel Configuration | SMD 3535 |
| Pixel Density | 15,625 pixels/m² |
| Module Dimensions(W*H)(mm) | 256*256 |
| Panel Dimensions(mm) | 1280*768*150 |
| NO. of Modules Per Panel (W*H) | 5*3 |
| Physical Resolution of Module (W*H) | 32*32 |
| Physical Resolution of Panel (W*H) | 160*96 |
| Panel Material | Steel/ Aluminum |
| Colors | 281 trillion |
| Brightness | >6,500 nits |
| Weight (kg/m²) | 65/45 |
| Processing | 16 bit |
| Refresh Rate | >1920 Hz |
| IP Rating | IP65/ IP54 |
| Viewing Angle | V:160 degree
H: 140 degree |
| Expected Lifetime | 100,000 Hrs |
| Operating Temp/Humidity | -20ºC-50ºC/
10%-90% |
| Storage Temp/Humidity | -20ºC-50ºC/
10%-90% |
| Avg./ Max. Power Consumption | 360/900W/ panel |
| Servicing | Front/Rear |
Digital Billboard Procesure Details
5.Long-term Brightness
6000-nit brightness(for outdoor full color) throughout product lifetime of the LED display.
6. 100% Waterproof LED module
100% waterproof module design,protection level IP65,PCS connections replace the
traditional electronic line which is safe and reliable.
7. Widely control system
we classified synchronous control and asynchronous control.Currently our asynchronous control can make use of USB,WIFI and 4G to transmitted.
Digital Billboard Images
Good heat dissipation and long Lifespan
Brightness can be adjusted automatically according to different surrondings,can be set to open and close the screen on fixed auctomatically, it can save half of electricity and improve the life of display.
Intelligent Software System
Intellighent control and player system by cloud technology.
Time management and real time minitoring
3. Digital Billboard Multiple installation methods
Digital Billboard Applications:
Ideal for dazzling different events, such as Stage, Concert, Fashion Show, Wedding, Conference, Building, Hotel, Club & Bars, Festival, etc.
About us
BAKO VISION product lines have include UHD fine pitch, I/O rental, I/O fixed install, transparent screen, advertising poster, foldable screen, flexible screen, curtain, floor LED, perimeter display… meanwhile, based on our experienced R&D team and comprehensive management, we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.
FAQ
1. I would like to ask you if it's possible to have my logo on the product.
A: We hope you know that our company perfectly support customized logo service. But, we also hope you know that it's an extra-service,so a little bit extra service fee is needed.
2. How to install it after I received it?
We will offer you the drawing to guide you for installation, we could also offer drawing, software set up drawing or photo or arrange our engineer to help if needed.
3. What is drive method, driving IC and power supply?
Drive method: always we use static, 1/4 scan, 1/8 scan, 1/16 scan, the latter one contributes to less brightness than the former. We always use the static outdoor, and use the different kinds of scan indoor.
Driving IC is the generic term for several kinds of IC, that are used to control the LED lamps, and as a bridge between the control system and lamps.
Power supply: a kind of device that used as a transfer from 220V AC into 5V DC. It always seems like a box in the cabinet.
